Summary

Author: Lukas M. Süss aka mechadense
Date: 2025-11-19

Description:
Left: A concatenative style projection
Right: Annotated lambda diagrams projection

Example is related to crystallographic CAD in general.
And specifically to AtomCAD:
https://github.com/atomCAD
