Summary
Date: 2023-03-21
Author: Lukas M.Süs aka mechadense
License: CC-BY-SA-4.0 / GFDL
Description:
Handsketch illustrating a positive locking mechanism and example usage
specifically in FFF printing context with printlayers making for
anisotropic material strength i.e. a notably weaker direction.
